PEGAS CrafTap SMART
Service Manual
Maintenance Safety Measures
  1. Do not disassemble or repair the device yourself. Service should be carried out by trained personnel.

  2. If it is necessary to disconnect the beverage supply hose for maintenance, wash the equipment before and after maintenance in accordance to this manual.

  3. Before starting repair / maintenance procedure of the device you must:
    – push the ON/OFF button to turn off the power;
    – unplug the AC/DC power adapter;
    – depressurize the beverage and gas supply line;
    – disconnect the GAS, BEER, and DRAINAGE hoses.

  4. Do not touch the contacts of electronic boards with bare skin or metal objects. This may cause damage to the device due to static voltage.

  5. Keep moisture away from electronic boards and cables. In case of moisture, wipe them dry with a lint-free cloth.

  6. Use certified bottles only capable of withstanding pressure of more than 5 bar. The bottle should not have chips, cracks and other damages.
REMEMBER!
Follow the operation and safety rules to ensure the product's long life
and safe operation.
Specifications
General View and Major Components
Mounting Dimensions
Unpacking of PEGAS CrafTap Smart
Take the device and all parts out of the package, check the contents, read the documentation. Use the mounting kit to install and connect the device. If necessary, use a special wrench to mount / dismount the filling unit.
Do not lose or throw away the spare parts kit.

The package also includes:

Documentation:
  • mounting template х 1 pc
  • CrafTap Smart quick guide х 1 pc
        Device parts:

        • rod х 1 pc
        • bottle holder with mat on it х 1 pc
        • bottle fixing handle х 1 pc
        Mounting parts kit:

        • nut М8 х 2 pcs
        • washer 8 mm х 2 pcs
        • pin М8 х 2 pcs
        • special wrench х 1 pc
        • straingt connector JG 3/8" Pl0412S х 4 pcs
        • tube to hose stem JG 3/8"-5/16" Pl251210S х 4 pcs
        • power supply adapter х 1 pc
        • power supply wire EUR L=1.2 m х 1 pc
        • power supply wire US L=1.5 m х 1 pc
        Spare parts kit:
        CTS filling mechanism o-rings set (art. 151030):
        • O-ring PG01.002 x 2pcs.
        • O-ring PG02.058 x 1pc.
        • O-ring 003 x 3pcs.
        • O-ring 006 x 2pcs.
        • O-ring 008 x 7pcs.
        • O-ring 016 x 2pcs.
        • Gasket PG21.004 x 1pc.
        Gasket x 1pc
        Push sealing x 1pc
        Installation and Connections
        The following is required:
        • drill with 13 mm (0.51") diameter drill bits
        • flat-head screwdriver
        • 13 mm (0.51") wrench
        • food grade LDPE hoses with 9.5 mm (3/8") outside diameter or food grade PVC hoses with 7 mm (1/4") inner diameter
        • hose clamps to fix flexible PVC hoses on nipples (if needed)
        • power jigsaw with a jigsaw blade
        • center punch/pin

        It is acceptable to use any other appropriate tools.
        To install and connect the device, please use the mounting parts kit (included in the packaging).
        1. Fix the mounting template
        and use a center punch or pin to make markings on the table board.
        2. Use a drill and power jigsaw to cut the holes in the table board according to markings.
        3. Use a screwdriver to screw pins into the threaded holes in the bottom of the filler.
        4. Place the filler on the counter top by aligning it with the pre-drilled holes.
        5. Put the washers on, screw the nuts onto the pins, and fix the filler on the table board by tightening the nuts with a wrench.
        6. Insert the rod into the center hole under the table board so that the threaded part of the rod protrudes out of the cam hole.
        7. Screw the bottle holder with a mat on it on the end of the rod as well as the bottle fixing handle to the appropriate location.
        8. Connect the gas, beverage supply, and drainage hoses to the appropriate tubes. See the connection scheme. Drainage consists of two hoses: one of the flask and another one of the filling head.
        9. Connect the CTS power supply adapter to the appropriate US/EU power supply wire under the table top and plug it in AC power line.
        10. Press the "On/Off" button at the rear cover to turn the CrafTap Smart on.
        WARNING!
        Make sure that the power supply settings meet requirements: 90 – 264 V, 47 – 63 Hz.
        Use the JG 3/8" straight connectors for LDPE hoses.
        Use the additional JG 3/8" - 5/16" tube to hose stems for PVC hoses.
        Fix hose ends with clamps.
        Single Beverage Connection Scheme


        The figure shows the connection scheme of Pegas CrafTap Smart using a cooler. If you use the cold room, supply the beverage directly from the keg coupler to PEGAS CrafTap Smart.
        IF YOU HAVE
        THE CRAFTPAD SMART

        Please, refer to the connection
        scheme below.

        Сontrol Panel
        User Menu
        You can also change the device settings such as beer type names, measure units, fill sizes, sounds etc. with Pegas Remote app. Beta version is available on App Store and Google Play.
        Cleansing
        1. Press the "MENU" button.
        2. Hold the "SET" button to start the cleansing procedure.
        3. The cleansing procedure takes 15 minutes.
        The display will work as a timer during process.
        The cleansing procedure can be stopped by pressing "1" "2" or "3" on the control panel.
        Setting the Sound
        1. Press the "MENU" button twice.
        2. Press the "SET" button.
        3. Adjust the sound with "+" and "–" buttons.
        sound is off

        button sounds only

        system sounds only

        all sounds
        are on

        4. Press "SET" or "MENU" to exit.
        Setting the Backlight
        1. Press the "MENU" button three times.
        2. Press the "SET" button.
        3. Adjust the backlight with "+" and "–" buttons.
        backlight is off

        logo
        backlight only

        flask
        backlight only

        backlight
        is always on

        flask backlight is on while filling, cleansing, calibration and purging.
        It turns off 20 sec. after finish, logo backlight is always off
        same as previous "2_0" setup, but logo backlight is always on
        4. For user convenience, the backlight settings are instantly applied without saving. Press "SET" to save settings or "MENU" to exit.
        SERVICE MENU
        Service Menu Entry
        1. Hold the "MENU" button.
        2. Enter your password using "1", "2" or "3" buttons. The default password is "2123". It's strongly recommended to change default password and keep the new password safe.
        3. The device is unlocked.
        WARNING!
        If not used for 20 sec., the service menu locks up. Enter your password to unlock it.
        Changing the Preset Sizes
         Available after accessing the service menu
        The preset fill sizes can be changed for "1", "2", and "3" buttons on the control panel with the help of this function.
        1. Press "SET".
        2. The current measure unit will be shown. Press the button "1", "2" or "3" to assign the volume.
        3. Adjust the fill size with "+" and "–" buttons.
        4. Press "SET" or "MENU" to exit.
        Setting the Measure Units
         Available after accessing the service menu
        1. Press the "MENU" button.
        2. Press the "SET" button.
        3. Adjust the units with "+" and "–" buttons.
        Liters

        American Ounces

        British Pints

        4. Press "SET" or "MENU" to exit.
        Setting the Bottle Purging Time
         Available after accessing the service menu
        Gas purging is performed to force the air out of the bottle before filling.
        1. Press the "MENU" button two times.
        2. Press the "SET" button.
        3. Adjust the purge time with "+" and "–" buttons.
        Time is displayed in seconds. Maximum purge time is 15 sec.
        4. Press "SET" or "MENU" to exit.
        Door Sensor Settings
         Available after accessing the service menu
        1. Press the "MENU" button three times.
        2. Press the "SET" button.
        3. Use "+" and "-" buttons to turn the sensor on or off.
        4. Press "SET" or "MENU" to exit.
        Calibration of PEGAS CrafTap Smart
        Available after accessing the service menu
        Calibration is needed if the amount displayed does not correspond with the actual amount poured. To calibrate, use a bottle larger than 1 liter which can withstand the pressure of no lower than 4 bar (58 psi). Use a low-foaming beverage.
        1. Press the "MENU" button four times.
        2. Hold the "SET" button to start the calibration procedure.
        3. Calibrate the device as described in Flowmeter Calibration section.
        Changing the Password
         Available after accessing the service menu
        For example your password is "2213".
        1. Press the "MENU" button five times.
        2. Press the "SET" button.
        3. Set the password with 4 digits by using "1", "2"
        and "3" buttons.
        enter
        the first digit

        enter
        the second digit

        enter
        the third digit

        enter
        the fourth digit

        4. Press "SET" or "MENU" to exit.
        Flow Meter Calibration
        Calibration is needed if the amount of beverage displayed does not correspond with the actual amount poured. To calibrate you will need a bottle of no less than 1 liter size and scales with an accuracy of 1 gram.
        1. Connect water to PEGAS CrafTap Smart.
        2. Beer supply line must be filled with water or beverage. To fill the line pour at least 0,5l (16 oz.) of water/beverage.
        3. Weigh the empty bottle on the scale and reset the scale.
        4. Put the bottle into device and fix it
        5. Start the calibration:


        Press the "MENU" button four times.
        6. Hold the "SET" button to start the calibration procedure.
        7. Wait until 1l is poured.
        8. When 1 liter is poured, take the bottle and check the actual volume poured. To do this, weigh the bottle on the scales.
        9. Enter the difference between the volume poured and 1 liter (in milliliters). For example, if the actual volume is 985 ml – press the "-" button until "-15" is on display.
        10. Press the SET button to save changes.
        We recommend to calibrate the device using the beverage connected to the device. In this case, do not perform steps 1 and 2 of this section.
        WARNING!
        When connected to the CraftPad Smart flow control switch step 2 of this section
        is essential.
        PEGAS CrafTap Smart Sanitisation
        For trouble-free service and fulfilment of the warranty obligations, we recommend servicing the device regularly. The short service manual provided can be used as a checklist. We recommend keeping it near your CrafTap Smart.

        Treatment Program

        * Or other similar solutions to wash and disinfect the internal surfaces of the process equipment for brewing and non-alcoholic industries.
        ** Or according to the manual of the detergent if another detergent-disinfectant is chosen.
        *** Until the wash water PH is neutral.

        As a manufacturer of the device, we recommend this treatment program. Please check if this hygienic plan corresponds with sanitary regulations in your country. The efficiency criterion of sanitary and hygienic activities is the final control and microbiological control, if necessary.
        For sanitization, the following is required:
        • Flush keg for treatment fluid, with a recommended volume of at least 20 l (5 gal)
        • Drain tank, recommended volume of at least 20 l (5 gal)
        • Neutral detergent
        • Alkaline detergent disinfectant
        • Acid detergent
        • Small volume flush bottle
        • Mini brush with a sponge or soft synthetic bristles
        • Flexible washing hose with outside diameter of 8 mm (5/16")
        • Personal protection equipment
            Preparation
            1. Disconnect the keg from the filler and turn your beer cooling system off, if possible. Empty the drain tank.
            2. Make sure that the ends of the flask and filling unit drain hoses are placed into an empty drain tank of the recommended volume.
            3. Open the CrafTap Smart door and place an empty flush bottle of a small volume on the bottle holder. Secure it against the filling head by turning the bottle fixing handle clockwise until the flush tank fixes, and close the protective door.
            4. Ensure that the gas cylinder pressure regulator is set at a pressure not higher than 1.2 bar (17.4 psi).
            Cleansing Procedure
            1. Choose the treatment type. Fill the flush keg with treatment fluid according to the table. Follow steps 1–5 from the next paragraph for every treatment fluid shown in the selected treatment type.
            2. Connect the keg coupler of the keg with beverage to the flush keg. Start the cleansing procedure on the CrafTap Smart and clean beverage supply
            for the time indicated in the table.
            WARNING!
            Use personal protection equipment while working with alkali and acid detergents.
            3. Press the "MENU" button.
            4. Hold "SET" button to start the cleansing procedure.
            5. The cleansing procedure takes 15 minutes.
            The display will work as a timer during the process.
            The cleansing procedure can be stopped by pressing "1" "2" or "3" on the control panel.
            WARNING!
            Do not open the door while the treatment fluid is being pumped through the filler.
            IF YOU HAVE
            THE CRAFTPAD SMART
            Wash each CraftPad Smart line separately. You should accomplish the cleansing through beer line #6.

            Disconnect the keg with beverage from the beer line to be cleaned and connect this beer line to the flush keg with treatment fluid. Select the corresponding button on CraftPad Smart.
            6. Clean the CrafTap Smart flask drainage by using a flexible washing hose with outside diameter of 8 mm (5/16"). Fill the drain tank. When it is full, empty it.
            7. Disconnect the keg coupler from the flush keg, without disconnecting gas and beverage supply. Empty the drain tank.

            To keep cleanliness till the next usage of the device, do not pour water used for beverage supply line washing.
            7. Do steps 2 – 6 for each stage of the chosen treatment type. If needed, do the cleansing as described below.


            8. Areas that contact with beverage in case of overflow must be sanitized daily. If needed, these areas can be washed through the drain hole with M7 (1/4") connecting thread.


            9. Remove two M3x8 screws using the L-shaped hex wrench Hex 2.0
            10. Slide up and remove control panel. Disconnect the CTS Display Cable from the CTS main board.
            11. Remove two M3x16 screws on each side of the cover with the hex wrench hex 2.0 and remove the side covers.
            12. Remove the cap M7 on the body of filling unit with S10mm (3/8") wrench.
            13. Screw the M7 fitting (not supplied) into the hole and connect the hose.
            14. Put the other end of the hose into the drain tank.

            15. Pump the treatment fluid through the device in accordance to the table.

            16. Assemble in reverse order.
            Before Pouring the Beverage
            Every treatment type ends with water rinsing. To remove water from the beverage supply line, start filling and drain it from the line into an empty transparent bottle placed and fixed in the CrafTap Smart. Keep draining the remaining liquid until the clean beverage starts to flow into the bottle.

            Then stop filling by pressing "1", "2" or "3" on the control panel.
            Final Stage
            1. Clean the flask drain channel with a mini brush, and then wipe the drain hole with a sponge dipped in warm water with a neutral detergent. Rinse with hot water.
            2. Remove the mat from the bottle holder. Twist the filling head bushing off, detach the rubber gasket, and remove the seal from the groove and the O-ring PG02.058 from the hole.
            3. Wipe the removed components with a sponge dipped in warm water with a neutral detergent. Perform assembly in reverse order.
            4. Wipe the inside surface of the flask with a sponge dipped in warm water with a neutral detergent.

            Then wipe the inside and outside surfaces of the flask with a clean wet cloth. Wipe the flask thoroughly inside and outside with a clean lint-free cloth until it is dry.
            Filling Unit Maintenance
            As a part of periodic maintenance, it is necessary to replace the sealing elements and lubricate moving parts of the filling unit annually.
            To be replaced:
            1. Gasket (art.132053), 1pc.
            2. CTS filling unit o-rings set (art. 151030):
            • O-ring PG01.002, 2pcs.
            • O-ring PG02.058, 1pc.
            • O-ring 003, 3pcs.
            • O-ring 006, 2pcs.
            • O-ring 008, 7pcs.
            • O-ring 016, 2pcs.
            • Gasket PG21.004, 1pc.
            To be lubricated:
            • Working surfaces of the cam in the drive of the device.
            • Sliding surfaces of the pressure flow valves and cap.
            We recommend the following lubricants for moving parts: Berulub SIHAF 2 or EFELE SG-391 FOOD LINE.
            WARNING!
            Before carrying out the maintenance read the Maintenance Safety Measures
            section carefully
            To disassemble / assemble device components or parts you will need:
            • L-shaped hex wrench Нex 2.0;
            • L-shaped hex wrench Нex 3.0;
            • Flat-head screwdriver SL 0.6 х 4.0;
            • Flat-head screwdriver SL 1.0 х 6.5;
            • Special wrench (М35 PG02.00.00.059) (included);
            • Wrench S10mm (3/8").
            Maintenance Procedure
            1. Remove two M3x8 screws using the L-shaped hex wrench Hex 2.0
            2. Slide up and remove control panel. Disconnect the CTS Display Cable from the CTS main board.
            3. Remove two M3x16 screws on each side of the cover with the hex wrench hex 2.0 and remove the side covers.
            4. Disconnect the door sensor from the CTS main board.
            5. Remove 4 screws M6x6, loose the CTS main board bracket fastening and dismantle the bracket by sliding up and slightly pulling.
            6. Disconnect six cables from the CTS main board: CTS pressure sensors cable, CTS optical sensors cable, CTS power cable, CTS flowmeter cable and CPS to CTS connection cables.
            7. Unscrew the hub with your hand. Remove the beer flow screw with flat-headed screwdriver SL 1.0 х 6.5.
            8. Remove the gasket from the hub, O-ring 008 with beer flow screw and O-ring PG02.058 from the hub hole.
            9. Push the collets on the body of CTS filling unit and disconnect the beer supply hose, gas supply hose and drainage hose with equal elbows.
            9. Use special wrench to unscrew the nut М35х1,5.

            10. Dismantle the CTS filling unit.
            11. Remove 2 screws М3х6 (Нex 2.0) and remove two clamps to loose CTS pressure sensors cables, CTS optical sensors cable and CTS drive assembly cable.
            12. Remove 3 screws M3x10 and dismantle CTS optical sensors.
            13. Remove 4 screws М3х16 (Нex 2.0).
            14. Push the collets in the mounting plate, remove polymeric pipes together with CTS pressure sensors.
            15. Remove 4 screws М4х20 (Нex 3.0), disconnect the CTS drive assembly.
            16. Unscrew two plugs M7 from the switch and the mounting plate with wrench S10mm.
            17. Remove O-ring 006 from both of the plugs М7.
            18. Remove 4 screws М4х20 (Hex 3.0) from the mounting plate and dismantle the plate.

            19. Remove O-ring 016 (2 pcs.) and O-ring 008 (2 pcs.) from the grooves of the switch.

            20. Remove 4 screws М3х6 (Hex 2.0) and take the cover off the mounting plate. Remove the gasket PG21.004 and O-ring 008.
            21. Remove 4 screws М4х20 (Hex 3.0) from the fitting plate to dismantle the plate.

            22. Remove O-ring 008 from the switch grooves.
            23. Fix valve caps and flow valve cap. Unscrew 2 valves with flat-headed screwdriver SL 1.0 х 6.5 and the flow valve with screwdriver SL 0.6 х 4.0
            24. Remove the O-ring 003 from the flow valve cap,
            O-ring PG02.058 (2 pcs.) from the valves and O-ring 003 (2 pcs.).
            Filling Unit Assembly
            Replace the sealing elements with new ones and assemble the filling unit.

            • Clean the valve surfaces and flow valve caps from the old lubricant, and apply the lubricant to the areas indicated in the figure below.

            • Apply a thin layer of thread-locker on the threads of the flow valve and valve caps, filling the thread.

            • Remove the old lubricant with a dry clean cloth and clean the cam surface with a neutral detergent solution.
              Lubricate the working surface of the cam as shown in the figure.

            Filling Unit Assembly Scheme
            WARNING!
            Leave the device at room temperature for 24 hours
            to polymerise the threadlocker before use.
            1. Put 2 rings O-ring PG02.058 onto two valves.
            2. Put 3 rings O-ring 003 onto two valves and the flow valve cap.
            3. Lubricate the working surface of the valves (see Filling Unit Assembly Scheme) and put them into the switch.
            4. Insert two springs into the switch valve channels, apply the thread-locker Loctite 2046 onto the thread of both caps. Screw the valves onto caps and position them as shown.
            5. Lubricate the working surface of the flow valve cap (see Filling Unit Assembly Scheme), apply the thread-locker Loctite 2046 onto the thread of flow valve. Insert the spring into the switch channel and compress the spring with flow valve cap. Screw flow valve into the cap as shown.
            6. Put O-ring 006 onto the plug and screw the plug into the switch.
            7. Insert gasket PG21.004 and O-ring 008 into the mounting plate and put the cover on. Fix the cover with 4 screws M3x6. Put O-ring 006 onto the plug and screw it into the mounting plate.

            8. Put two O-ring 008 and two O-ring 016 into switch grooves. Assemble the switch and mounting plate with 4 screws M4x20.
            9. Put three O-ring 008 into the grooves on the switch. Assemble the switch and fittings plate with 4 screws M4x20.
            10. Install the drive assembly onto the filling unit without electronics (cam mounting position, see Filling Unit Assembly Scheme). Fix the unit with 2 centering conical screws M4x20 then screw other 2 screws M4x20.
            11. Install optical sensors onto the filling unit and fix them with 3 screws M3x10.
            12. Install two the CTS pressure sensors into cartridges JG1/4" and fix them with 4 screws M3x16.
            13. Fix the optical sensors cables, the pressure sensors cables and drive cable with clamps.
            13. Fix the main board bracket on the filling unit with 4 screws M3x6;

            Fix the main board on the bracket with three screws M3x6.

            Connect the pressure sensors cable, optical sensors cable and drive cable to the main board.
            14. Put the filling unit onto device. Position it by thread M35 and the fixing screw. Fix the filling unit with special wrench. Connect the reed sensor to the main board.
            15. Connect the CraftPad Smart cable, flow meter cable to CraftTap Smart.
            16. Connect the beer supply hose, gas supply hose and drainage hose (left to right) with equal elbows. Connect power cable to CraftTap Smart.
            17. Connect the two side covers and install them on the filling unit and fix with two black screws M3x16.
            18. Put the control panel on the cover.
            19. Fix the control panel with two screws M3x8.
            20. Put O-ring 008 onto the beer flow screw. Fix the beer flow screw with flat-headed screwdriver.

            21. Insert the gasket into the bushing and insert the O-ring PG02.058 into the bushing hole.
            Bottle Fixing Mechanism Maintenance
            As a part of periodic maintenance, it is necessary to replace the sealing elements and lubricate moving parts of the bottle fixing mechanism annually. Before maintenance the bottle fixing mechanism needs to be dismantled.

            To be replaced:
            • Push sealing – 1pc. (art. 132098)

            To be lubricated:
            • Surface contacting the push sealing;
            • Moving elements of the bottle fixing mechanism.

            We recommend the following lubricants for moving parts: Berulub SIHAF 2 or EFELE SG-391 FOOD LINE.
            The use of other lubricants is permitted.
            WARNING!
            Before carrying out the maintenance read the Maintenance Safety Measures
            section carefully
            To disassemble / assemble device components or parts you will need:
            • Wrench S8;
            • L-shaped hex wrench Нex 4.0
            Dismantle the Bottle Fixing Mechanism
            1. Dismantle the Pegas CrafTap Smart.

            2. Unscrew the bottle holder with mat.

            3. Unscrew two handles from the bottle fixing mechanism.
            4. Unscrew the handle together with a locknut and handle screw with wrench S8 mm.
            5. Unscrew 4 screws M6 with hex wrench HEX 4.0.

            6. Take the fixing mechanism out of the device.
            7. Dismantle the push sealing.
            Lubrication of Moving Parts
            Parts of the mechanism must be clean. Clean the parts with sponge and neutral detergent prior to lubrication.
            Checking and lubrication of return spring.

            If the cam does not return to the initial position, the rerun spring needs to be replaced and lubricated.

            1. Unscrew and take out the bushing, pick the cam and extract the return spring.

            2. Remove old lubricant;

            3. Apply plenty of lubricant onto the spring surface and mounting seat;

            Install the bottle fixing mechanism in the reverse order:

            1. Put the return spring into the mounting seat;

            2. Install the cam onto the bottle fixing mechanism with groove facing the spring;

            3. Screw the bushing.


            Lubricate the indicated areas of the bottle fixing mechanism.
            Installing the Bottle Fixing Mechanism
            1. Insert the push sealing into device.
            2. Put the cam through the bottom hole of the flask and the cables through the holes of the bottle fixing mechanism.

            3. Fix the mechanism with 4 screws М6х16.
            4. Place the handle screw into the bottle fixing mechanism. Fix the locknut and the handle onto the handle screw.
            5. Screw two handles into the cam of the bottle fixing mechanism and screw the bottle holder onto the rod.
            Firmware Update
            For stable and reliable work of CrafTap Smart make sure your device firmware is up to date.

            Contact the official distributor in your country to find out about the latest version of the firmware or feel free to contact us: https://beerinnovations.com/service

            You can check your current firmware version in Pegas Remote app.
            Checking the Firmware Version
            1. Connect to CrafTap Smart via Wi-Fi and run Pegas Remote app. Open Settings.

            2. Go to Device
            3. Check your current firmware version of CrafTap Smart and CraftPad Smart (if used).
            Updating Process
            To update the firmware you need:
            1. Open the USB cap on the side cover.

            2. Connect the cable to the connector on the main board.

            3. Press ON/OFF to turn on the power.

            4. Connect the cable to your PC.
            WARNING!
            Administrative rights are required to install the software onto your PC.
            5. Run SmartFlasherSetup.exe from the Installer folder.
            6. Press Next in a dialogue box.
            7. Press Install.
            8. Press Close when the installation is completed.
            9. Go to SmartFlasherSetup\drivers\win and run install_drivers.exe
            10. Wait until process is completed. Accept any requests from Windows OS if they appear.
            11. Press any key after the installation is completed.
            12. You can find Maple serial (COMx) device in Device Manager now.
            13. Run Smart Flasher.exe and chose the file with firmware update and press Upload.
            14. You will see Finished! when updating is completed.

            15. You may check new firmware version in Pegas Remote app on your smartphone.
            TROUBLESHOOTING
            Error messages and fixing recommendations

            E0 – No power supply
            Make sure that the device is plugged in.

            E1 – Pressure is lower than 0.5 bar (7 psi)
            Increase the pressure using the regulator on the gas cylinder.

            Е2 – Pressure is higher than 3 bar (43 psi)
            Reduce the pressure by using the regulator.

            E3 – The beverage is over
            Change the keg.

            E4 – The bottle is not fixed or is absent
            Make sure that the bottle is fixed correctly.

            E5 – The door is opened
            Close the protective door and repeat the procedure.

            E6 – Beer sort is not chosen (if CraftPad Smart in use)
            Chose the beer sort by pressing the button with corresponding number (1 to 6) on CraftPad Smart.

            E9 – Hardware error
            Contact the service center.
            © NPM
            PEGAS Fillers
            Help
            Business
